OUTDOOR
PANEL
A4-D0106TM-G
Stainless steel outdoor panel. Unlockable
via a password. Waterproof. Anti-vandal.
PRODUCT DETAILS
| Resolution | 700 TVL |
| Camera | CMOS |
| Working voltage | DC 14.3V |
| Working current | ≤200mA |
| Illumination | 0.05 LuX |
| Talking duration | 120S |
| Working temperature | -20～＋55℃ |
| IP rating | 55 |
| Installation | Flush mounted/Surface mounted |
| View angle | 110° angle view |
| H/W/D | 250x120x50 (mm) |
| Cable | RVV4.0x0.5/RVV4.0x0.75 |
SURFACE MOUNT BOX
OUTDOOR
PANEL
A4-D0106TM-G
Stainless steel outdoor panel. Unlockable
via a password. Waterproof. Anti-vandal.
PRODUCT DETAILS
| Resolution | 700 TVL |
| Camera | CMOS |
| Working voltage | DC 14.3V |
| Working current | ≤200mA |
| Illumination | 0.05 LuX |
| Talking duration | 120S |
| Working temperature | -20～＋55℃ |
| IP rating | 55 |
| Installation | Flush mounted/Surface mounted |
| View angle | 110° angle view |
| H/W/D | 250x120x50 (mm) |
| Cable | RVV4.0x0.5/RVV4.0x0.75 |
SURFACE MOUNT BOX
OUTDOOR PANEL
A4-D0106TM-G
Stainless steel outdoor panel. Unlockable via a password. Waterproof. Anti-vandal.
PRODUCT DETAILS
| Resolution | 700 TVL |
| Camera | CMOS |
| Working voltage | DC 14.3V |
| Working current | ≤200mA |
| Illumination | 0.05 LuX |
| Talking duration | 120S |
| Working temperature | -20～＋55℃ |
| IP rating | 55 |
| Installation | Flush mounted/Surface mounted |
| View angle | 110° angle view |
| H/W/D | 250x120x50 (mm) |
| Cable | RVV4.0x0.5/RVV4.0x0.75 |
SURFACE MOUNT BOX
